Crude oil gathering & transfer
Temperature conditioning for oilfield gathering and station piping.
ISO-Certified Manufacturer
ISO 9001 · 14001 · 45001Induction Process Heater
for Oilfield Fluids
Electromagnetic heating for crude oil and produced liquids, configured around your process and station requirements.
Equipment OverviewHeat generated in the metal.
Heat generated in the metal.
Transferred to the process fluid.
An alternating magnetic field induces currents in the metal heating tube. Heat is generated in the metal itself and transferred through the tube wall to crude oil or produced liquids flowing through the designed passages.
The induction winding is separated from the process fluid. The heated tube wall remains a wetted heat-transfer surface, so wall temperature, deposits and minimum-flow protection still matter. Heater units and complete skid packages are configured around your specification.
Discuss Your Requirements
Induction heat generation
Magnetic-field energy produces heat in the metal tube.
Engineered flow passages
Heating length and return flow balanced against pressure drop.
Unit or complete package
Heating units, piping, instrumentation and controls supplied together.
Applications & Operating ConditionsControlled heating for crude oil
Controlled heating for crude oil
and produced liquids.
Water cut, viscosity, sand content and scaling tendency are reviewed with the required temperature rise and operating flow range.
Water-cut produced liquids
Heating duty reviewed against oil-water composition and operating flow.
Pre-separation heating
Outlet temperature matched to the downstream separation process.
Cold-region operation
Viscosity control, insulation and winter start-up reviewed together.
Heating Principle & EngineeringMatch the heated wall
Match the heated wall
and the fluid passage.
The metal heating tube and induction winding form a matched assembly. Distributed winding and an extended heating section support the agreed heat-transfer duty. Internal passages, return-flow connections and drain access are selected for the fluid and maintenance requirements.
Heat generation and flow arrangement are separate design choices. A longer return-flow path must be checked for pressure loss and minimum flow; it does not establish a fixed increase in efficiency. Sand, scale and low flow can still create hot spots at the wetted wall.
- Allowable wall temperature and heat loading based on crude properties and fouling risk.
- Heating length, flow velocity and pressure drop reviewed together.
- Drain locations and cleaning access selected for solids-bearing service.
- Power-factor correction and harmonic filtering reviewed for the site network; they do not establish a fixed process-energy saving.
PLC / PID regulation
Temperature feedback regulates the power-control stage through the agreed control signal.
Local & remote operation
Local controls, remote start / stop and RS485 Modbus RTU interfaces for station control.
Shell & core temperature
Warnings and protective trips have separate roles; latched trips require investigation and manual reset.
Process & electrical protection
Minimum-flow, pressure and electrical-fault protection configured for the installation.
Technical Data & Delivery Scope
Request a Datasheet Review the details that matter.
Published ranges describe configurable heater units. Multi-unit packages can serve larger duties; final ratings and certification are confirmed for the selected configuration.
Specifications
| Specification Parameters | Specification Details |
|---|---|
| Rated Voltage | AC 380 V, 50 Hz (customizable) |
| Rated Power | Up to 500 kW per unit |
| Inlet/Outlet Specification | Custom flange / nozzle sizes |
| Control Mode | PLC / microcontroller / digital controller (optional) |
| Alarm Mode | Shell / core over-temperature; flow, pressure and electrical faults |
| Design Pressure | Up to 9.9 MPa |
| Control Cabinet | Explosion-proof / non-explosion-proof |
| Protection Class | IP65 |
| Explosion-Proof Grade | IIB / IIC; temperature class by configuration |
Standards & Certification
| Standards and Certification Area | Reference / Route | How XGTHERMAL Supports It |
|---|---|---|
| Explosion-proof design basis | IEC 60079 / GB/T 3836 | Applicable requirements for the induction heating assembly, enclosure, terminals and hazardous-area electrical equipment. |
| EU / international Ex certification | ATEX / IECEx | Project-specific certification route can be supported when required by the destination market and final hazardous-area classification. |
| Eurasian market access | EAC / TR CU 012/2011 | Certification and technical documentation support can be coordinated for Russia, Kazakhstan and other EAEU destinations. |
| Oil & gas procurement documents | IOGP JIP33 S-723 Electrical Process Heaters | S-723 primarily covers resistance-type heater bundles. Relevant procurement clauses may be reviewed with the EPC for an induction package; no blanket S-723 compliance is implied. |
| Pressure boundary | ASME BPVC Section VIII / PED 2014/68/EU | Pressure design, material traceability, welding records and third-party review can be supported when the heater body is within project pressure-equipment scope. |
| Electrical cabinet and machine safety | IEC 61439 / IEC 60204-1 | Control cabinet layout, component selection, wiring practice and electrical protection can be configured around project requirements. |
| Functional safety | IEC 61511 / SIL | SIL-rated safety loop design can be coordinated when independent shutdown or safety instrumented functions are specified. |
| Sour service materials | ISO 15156 / NACE MR0175 | Material selection can be reviewed for H 2 S or sour crude service when required by the process medium. |
| Inspection and handover package | EN 10204 3.1, NDT reports and FAT records | Material certificates, pressure test records, non-destructive testing reports, electrical test records and factory acceptance test files can be supplied. |
| Ingress protection | IEC 60529 | IP65 / IP66 enclosure protection can be selected for outdoor oilfield stations and harsh operating environments. |
Certification availability depends on the final equipment configuration, destination market, hazardous-area classification and third-party assessment. Listed standards describe engineering and documentation support, not blanket certification for every configuration.
Supply Scope
| Name | Origin/Brand | Remarks |
|---|---|---|
| Heater Body | Shenyang Xinguang Electric Manufacturing Co., Ltd. | Pressure boundary and process connection customized by project |
| Induction Heating Assembly | Shenyang Xinguang Electric Manufacturing Co., Ltd. | Heating tube, winding and insulation configured for duty and fluid properties |
| Control Cabinet | Shenyang Xinguang Electric Manufacturing Co., Ltd. | Explosion-proof or safe-area cabinet available |
| Electrical Components | Delixi, Chint or project-approved equivalents | PLC, power regulator, breakers, contactors, relays and filtering options |
| Instruments | Chuanyi, Anhui Tiankang, Beijing Tiantai or project-approved equivalents | Temperature, pressure, flow and level instruments configured by process design |
Selection SupportFrom operating conditions
From operating conditions
to a practical equipment review.
Start with mass flow, representative specific heat and the required temperature rise. Final selection also checks wall temperature, fluid velocity, pressure drop and induction-coil loading.
What to share with our team.
Send your datasheet and representative fluid properties. Water-cut, solids-bearing or multiphase streams need a project review; a generic oil property cannot reliably establish equipment rating. The heat-duty relationship Q = ṁ × Cp × ΔT is a starting point for suitable single-phase liquid service.
- Fluid composition and water cut
- Normal operating flow rate
- Minimum / maximum flow and turndown
- Inlet and target outlet temperature
- Design pressure and flange standard
- Allowable pressure drop
- Viscosity, wax tendency, sand and scale characteristics
- Allowable heated-wall temperature and surface heat load
- Hazardous-area classification
- Start-up and turndown conditions
- Power supply and site electrical limits
- Heater body or skid-mounted package
- Local panel, PLC, Modbus RTU, SCADA or DCS interface
Common engineering questions.
Is an electromagnetic heater the same as an induction heater?
On this page, induction heater and electromagnetic heater describe the same heating method: an energized winding induces currents in a metal heating tube. This is a flow-through process heater, not an induction tool for bearing installation or metal hardening.
Can it handle water-cut crude oil and sand-bearing fluid?
Yes. The design can be configured for crude oil and water-cut produced liquids after reviewing viscosity, solids, water chemistry and scaling tendency. Drainage access helps maintenance; it does not replace a sand separator or remove the need for periodic cleaning.
Does oil contact the energized coil?
The induction winding is separated from the process fluid. Heat crosses the metal tube wall into the fluid, so that wall can still foul or overheat if flow is lost. Electrical isolation does not eliminate the need for hazardous-area design and independent protective shutdown.
Can it be supplied as a skid-mounted package?
Yes. Multiple heating units can be integrated with skid piping, valves, instruments, insulation and control cabinets. The Oilfield Transfer Station Induction Heating Project below is a 600 kW package reference, not a universal rating for every heater unit.
Do you manufacture induction heaters in China for overseas projects?
Yes. XGTHERMAL is a China-based manufacturer of explosion-proof induction heaters and packaged oilfield heating equipment. We support project-specific engineering, technical documentation and export-oriented communication for overseas procurement teams.
What certification documents can be supported?
Applicable Ex and pressure-equipment documentation is agreed during selection. ATEX, IECEx or EAC assessment can be coordinated when required; a route is not an existing certificate for every configuration. If JIP33 S-723 is specified, the EPC must review its applicability because its primary scope is resistance-type heater bundles.
Manufacturing & Project ExperienceReview the assembly.
Review the assembly.
Then review the field application.
Manufacturing since 1992, with 120+ projects delivered across our industrial heating equipment range.
Review Our Capabilities
Oilfield Transfer Station Induction Heating Project
A 600 kW skid-mounted electromagnetic induction heating package for water-cut crude oil at a cold-region transfer station. The case demonstrates the same product family with local operation and station-control communication.
