Sand-bearing crude oil heating
Combines a controlled heat source with provision for collecting entrained sediment.
ISO-Certified Manufacturer
ISO 9001 · 14001 · 45001Sand-Settling Electric
Process Heater
Indirect electric heating with dedicated sediment collection and blowdown access for sand-bearing oilfield fluids.
Equipment OverviewHeat the liquid.
Heat the liquid.
Make provision for the solids.
XGTHERMAL’s Oilfield Sand-Settling Electric Heater uses a vertical configuration combining vacuum-assisted phase-change indirect heating, pipeline swirl / flow-path design and dedicated sediment-collection space for sand-bearing crude oil and produced liquids. Periodic blowdown provides a means of removing accumulated solids.
Manufactured in China for oilfield gathering stations, the system uses PLC-based centralized heating control. Heating duty, fluid passages, settling space and drain access are configured around viscosity, flow rate and solids loading, so heating and sediment removal can be planned together.
Discuss Your Requirements
Indirect electric heating
Phase-change heat transfer separates electric elements from crude oil.
Dedicated settling space
Provision for sediment collection within the process arrangement.
Planned blowdown
Collected solids removed at intervals matched to operating conditions.
Applications & Operating ConditionsHeating and sediment management
Heating and sediment management
at gathering stations.
This configuration is intended for gathering-station duties where sand accumulation complicates routine heating and maintenance. Selection starts with the produced-fluid composition and the solids to be managed, as well as the required outlet temperature.
Produced-liquid temperature conditioning
Raises oil-water mixture temperature to the target specified for the gathering process.
Viscous crude oil handling
Supports fluidity while allowing solids accumulation and cleaning access to be considered.
Seasonal temperature variation
Matches the heating arrangement and insulation to changing inlet and ambient temperatures.
Gathering-station heating upgrades
For projects where an existing heating arrangement needs better provision for sediment collection and removal.
Engineering & IntegrationIndirect heat transfer.
Indirect heat transfer.
Space for sediment collection.
Electric elements heat an intermediate phase-change medium, which transfers heat indirectly to the process fluid through a separate heat-transfer surface. The process-side arrangement combines pipeline swirl features with sand-settling space and blowdown access. The heating circuit and the process-fluid pressure boundary are reviewed separately during engineering.
Heating and sediment removal are related but distinct requirements. Particle size, solids concentration and fluid viscosity determine the settling arrangement. Periodic blowdown requires suitable isolation, access and a defined discharge destination.
- Process-side materials and passages reviewed for erosion, deposits and fluid compatibility
- Intermediate heating medium and heat-transfer area selected for the required duty
- Settling space and drain access matched to the expected solids loading and removal plan
- Instrumentation, insulation and cabinet arrangement coordinated with site requirements
PLC-based centralized control regulates the heating process. Monitoring, protection, alarms and interlocks are configured according to the final process conditions, heater architecture and project control philosophy; not every configuration includes every function listed below. Sediment removal is a separate operating task: the blowdown sequence, isolation arrangement and discharge destination must be defined for the installation.
PLC temperature regulation
Process temperature feedback supports controlled heat input and local operating visibility.
Independent temperature protection
Independent high-limit monitoring can be configured separately from normal temperature regulation according to the selected heating arrangement and project protection requirements.
Flow and heating-medium level
Flow and liquid-level alarms or interlocks can be selected to inhibit heating under unsuitable conditions.
Pressure protection and blowdown coordination
Process-side and heating-circuit pressure protection are reviewed separately. Electrical-fault trips and the agreed blowdown operating sequence complement the temperature controls; automatic sand discharge is not assumed.
Technical Data & Delivery Scope
Request a Datasheet Review the details that matter.
Published options provide a starting point. Final ratings, pressure boundaries and certification requirements follow your selected configuration.
Specifications
| Specification Parameters | Specification Details |
|---|---|
| Rated Voltage | AC 380 V, 50 Hz (customizable) |
| Rated Power | Up to 500 kW |
| Inlet/Outlet Specification | Custom flange / nozzle sizes |
| Control Mode | PLC centralized control; other configurations by project agreement |
| Alarm Mode | Temperature, pressure, flow, level and electrical faults (optional) |
| Design Pressure | Project-specific pressure rating |
| Control Cabinet | Explosion-proof / non-explosion-proof |
| Protection Class | IP65 |
| Explosion-Proof Grade | IIB / IIC; temperature class by configuration |
Standards & Certification
| Standards and Certification Area | Reference / Route | How XGTHERMAL Supports It |
|---|---|---|
| Explosion-proof design basis | IEC 60079 / GB/T 3836 | Applicable requirements for electrical heating components, terminals, cabinets and other hazardous-area equipment. |
| EU / international Ex certification | ATEX / IECEx | Project-specific certification route can be supported when required by the destination market and final hazardous-area classification. |
| Eurasian market access | EAC / TR CU 012/2011 | Certification and technical documentation support can be coordinated for Russia, Kazakhstan and other EAEU destinations. |
| Oil & gas procurement documents | IOGP JIP33 S-723 Electrical Process Heaters | Applicable procurement clauses and documentation can be reviewed with the EPC. The indirect heating and settling package requires a scope review; S-723 does not establish sand-separation performance. |
| Pressure boundary | ASME BPVC Section VIII / PED 2014/68/EU | Process-side and heating-circuit pressure boundaries, material traceability, welding records and applicable conformity assessment are reviewed for the destination market. |
| Electrical cabinet and machine safety | IEC 61439 / IEC 60204-1 | Control cabinet layout, component selection, wiring practice and electrical protection can be configured around project requirements. |
| Functional safety | IEC 61511 / SIL | Functional-safety requirements and any required SIL target are evaluated at project level for the specified control and protection functions; this is not a blanket SIL certification of the heater. |
| Sour service materials | ISO 15156 / NACE MR0175 | Material selection can be reviewed for H 2 S or sour crude service when required by the process medium. |
| Inspection and handover package | EN 10204 3.1, NDT reports and FAT records | Material certificates, pressure and electrical test records, NDT reports and FAT documentation can be provided according to the approved project inspection and test plan / specification. |
| Ingress protection | IEC 60529 | IP65 / IP66 enclosure protection can be selected for outdoor oilfield stations and harsh operating environments. |
Certification availability depends on the final equipment configuration, destination market, hazardous-area classification and third-party assessment. Listed standards describe engineering and documentation support, not blanket certification for every configuration.
Supply Scope
| Name | Origin/Brand | Remarks |
|---|---|---|
| Heater Body | Shenyang Xinguang Electric Manufacturing Co., Ltd. | Process body, settling space and connections configured by project |
| Heating Element | Shenyang Xinguang Electric Manufacturing Co., Ltd. | Electric elements matched to the intermediate heating medium and duty |
| Control Cabinet | Shenyang Xinguang Electric Manufacturing Co., Ltd. | Explosion-proof or safe-area cabinet available |
| Electrical Components | Delixi, Chint or project-approved equivalents | PLC, circuit breaker, contactor, thyristor, relay and isolating barrier options |
| Instruments | Chuanyi, Anhui Tiankang, Beijing Tiantai or project-approved equivalents | Process and heating-circuit temperature, pressure, flow and level monitoring |
Selection SupportFrom operating conditions
From operating conditions
to a practical equipment review.
Thermal sizing starts from Q = ṁ × Cp × ΔT. Sand-settling selection also considers particle-size information, solids loading, fluid viscosity and flow variation. These parameters are reviewed when evaluating the flow path, solids-settling arrangement and maintenance strategy; the blowdown interval also depends on field operating history.
What to share with our team.
Share your process conditions, solids data, drawings and maintenance requirements. Heating duty and settling performance are separate selection requirements; a liquid heat-duty estimate cannot establish sediment-removal capacity.
- Produced-fluid composition and water cut
- Normal flow rate and operating schedule
- Minimum / maximum flow and transient conditions
- Inlet and target outlet temperature
- Design pressure and flange standard
- Allowable pressure drop
- Viscosity, wax, scale and emulsion characteristics
- Sand concentration and particle-size distribution
- Hazardous-area classification
- Solids-removal target and available blowdown destination
- Power supply and site electrical limits
- Installation space, inspection access and maintenance intervals
- Local / remote controls and station interlocks
Common engineering questions.
Is this the same as a dedicated oilfield desander?
A sand-settling heater combines heating with space for sediment collection and removal. A dedicated desander is selected around separation performance. Where an outlet-solids limit or particle cut size is specified, the complete separation duty must be assessed; heating power alone cannot establish that performance.
Which fluids and solids can be evaluated?
The intended service includes sand-bearing crude oil and produced liquids at gathering stations. Suitability depends on particle sizes, concentration, water cut, viscosity, flow range and fouling behavior. Fine suspended solids and emulsions require separate process evaluation rather than an assumption of complete removal.
Do the electric elements contact crude oil directly?
Electric heating elements act on an intermediate phase-change medium rather than being immersed directly in the crude oil. The process fluid still contacts a heat-transfer wall, so deposit buildup and abnormal wall temperature must be considered during selection and operation.
Is sand discharge automatic or continuous?
The existing product design provides sand-settling space and periodic blowdown. The removal interval depends on actual solids accumulation and operating conditions. Automatic valve sequencing or continuous discharge should only be included when specifically engineered and agreed; it is not assumed as standard.
Do you supply sand-settling heaters from China?
Yes. XGTHERMAL is a China-based manufacturer of electric heaters and integrated heating equipment for oilfield gathering stations. We support project-specific configuration, technical documentation and overseas procurement discussions for sand-bearing fluid heating duties.
What certification documents can be supported?
The documentation package can include applicable Ex assessment, material certificates, pressure and electrical test records, and FAT documentation. Destination-specific ATEX, IECEx or EAC routes are agreed for the final equipment. Certificates for one configuration do not automatically cover every project.
Manufacturing & Custom EngineeringReview the equipment.
Review the equipment.
Define the site interfaces.
Manufacturing since 1992, with 120+ projects delivered across our industrial heating equipment range. XGTHERMAL has supplied electric heating systems for projects connected with CNPC / PetroChina, PipeChina and Sinopec.
Review Our CapabilitiesCustom engineering around your operating conditions.
Share the operating conditions, installation limits and control requirements. We configure the equipment and define process connections, electrical interfaces and maintenance access with your team.
- Produced-fluid composition, water cut, sand loading and fouling tendency.
- Process connections, pressure ratings, footprint and blowdown access.
- Hazardous-area classification, IP protection, grounding and interlocks.
- Local HMI, station signals and temperature-control requirements.
Qualified procurement discussions can include redacted cooperation records, contract references or project supporting materials.
Review Project ExperienceHave a specification?
Let’s review it together.
Share your process conditions, drawings and delivery requirements.
