Skid assembly
Two 100 kW heater skids with piping, valves, relief equipment and instruments.
ISO-Certified Manufacturer
ISO 9001 · 14001 · 45001Pipeline Delivery Station Gas Heating Project
Two 100 kW heating skids arranged for duty and standby service at a natural gas delivery point.
Project overview
Application and supply scope.
The project configuration below summarizes the supplied equipment and its process application.
- Year
- 2024
- Region
- Hunan, China
- Application
- Gas delivery and pressure-reduction heating
- Supply scope
- Two integrated electric heater skids
The engineering challenge
Conditions shaping the heating duty.
Pressure-reduction cooling at a new pipeline delivery point created hydrate and freeze-blockage risks for downstream station equipment.
The site required hazardous-area equipment, continuity of gas supply and local operation with remote visibility.
Equipment configuration
What the package includes.
Equipment capacities, interfaces and controls are matched to the project application.
- Installed arrangement
- 2 × 100 kW; one duty + one standby
- Equipment
- Vertical explosion-proof resistance heater skids
- Control
- Local HMI; automatic outlet-temperature regulation
- Communication
- RS485 Modbus RTU / SCADA
- Field configuration
- Ex d IIB T4 Gb; IP65
- Protection
- Two-stage overtemperature, low flow, pressure relief and electrical protection
Package scope & interfaces
Beyond the heater body.
The integration and handover scope documented for this project.
Electrical & controls
Junction boxes, control cabinets, local HMI and outlet-temperature regulation.
Plant interfaces
Defined mechanical and electrical boundaries with RS485 Modbus RTU / SCADA communication.
Our approach
Engineering the complete heating package.
Duty and standby arrangement
Two complete 100 kW skids allow standby availability for maintenance or protected shutdown, subject to the station operating strategy.
Factory-integrated supply
The scope includes heater bodies, piping, valves, relief equipment, instruments, junction boxes and control cabinets, giving the site a defined mechanical and electrical connection boundary.
Temperature and protection logic
Closed-loop outlet-temperature control is combined with staged overtemperature and low-flow protection. Modbus communication supports setpoint exchange, power feedback, alarms and status monitoring.
Project value
Delivery and application value.
Process objective
The packages provide temperature compensation around pressure reduction to reduce hydrate and ice-blockage risk and support downstream valves and instruments.
Delivery value
Integrated skid supply reduces dispersed site assembly. No quantified availability or commissioning-time improvement is claimed in this summary.
